| 250 Vac, 50 Hz, single Phase 单相电容250Vac额定电压，长方形（电网电压220Vac选配6-7%电抗） |
Aerovox P/N
产品料号 |
KVAR Rating under 250Vac
在250Vac下的额定千乏数
kvar |
Rated Current
额定电流
(A) |
Rated Capacitance
额定电容值
(µF) |
Dimensions
尺寸
L x W x H (mm) |
Approx Weight
大约重量
(kg) |
| ADCA015RK11W |
5 X 3 |
20 X 3 |
255 X 3 |
200X130X350 |
6.00 |
| ADCA030RK11W |
10 X 3 |
40 X 3 |
510 X 3 |
330X130X350 |
9.50 |
| ADCA040RK11W |
13.3 X 3 |
53.4 X 3 |
680 X 3 |
330X130X450 |
12.30 |
| ADCA045RK11W |
15 X 3 |
60 X 3 |
764 X 3 |
330X130X450 |
12.60 |
| ADCA060RK11W |
20 X 3 |
80 X 3 |
1019 X 3 |
330X130X570 |
15.40 |
| 280 Vac, 50 Hz, single Phase 单相电容280Vac额定电压，长方形（电网电压220Vac选配13-14%电抗） |
Aerovox P/N
产品料号 |
KVAR Rating under 280Vac
在280Vac下的额定千乏数
kvar |
Rated Current
额定电流
(A) |
Rated Capacitance
额定电容值
(µF) |
Dimensions
尺寸
L x W x H (mm) |
Approx Weight
大约重量
(kg) |
| ADCA015RM11W |
5 X 3 |
17.8 X 3 |
203 X 3 |
200X130X350 |
6.00 |
| ADCA030RM11W |
10 X 3 |
35.7 X 3 |
406 X 3 |
330X130X350 |
9.50 |
| ADCA040RM11W |
13.3 X 3 |
47.5 X 3 |
542 X 3 |
330X130X450 |
12.30 |
| ADCA045RM11W |
15 X 3 |
53.6 X 3 |
609 X 3 |
330X130X450 |
12.60 |
| ADCA060RM11W |
20 X 3 |
71.4 X 3 |
812 X 3 |
330X130X570 |
15.40 |
| 440 Vac, 50 Hz, 3 Phase 三相电容440Vac额定电压，长方形（电网电压380Vac选配6-7%电抗） |
Aerovox P/N
产品料号 |
KVAR Rating under 440Vac
在440Vac下的额定千乏数
kvar |
Rated Current
额定电流
(A) |
Rated Capacitance
额定电容值
(µF) |
Dimensions
尺寸
L x W x H (mm) |
Approx Weight
大约重量
(kg) |
| ADCA005RJ33D |
5 |
7 |
82 |
200X130X350 |
4.70 |
| ADCA010RJ33D |
10 |
13 |
164 |
200X130X350 |
4.90 |
| ADCA015RJ33D |
15 |
20 |
247 |
200X130X350 |
5.00 |
| ADCA020RJ33D |
20 |
26 |
329 |
200X130X350 |
6.20 |
| ADCA025RJ33D |
25 |
33 |
411 |
200X130X350 |
6.90 |
| ADCA030RJ33D |
30 |
39 |
493 |
200X130X350 |
7.00 |
| ADCA040RJ33D |
40 |
52 |
658 |
330X130X350 |
9.90 |
| ADCA050RJ33D |
50 |
66 |
822 |
330X130X450 |
12.30 |
| ADCA060RJ33D |
60 |
79 |
987 |
330X130X450 |
13.10 |
| ADCA070RJ33D |
70 |
92 |
1151 |
330X130X570 |
15.70 |
| ADCA080RJ33D |
80 |
105 |
1316 |
330X130X570 |
17.10 |
| 480 Vac, 50 Hz, 3 Phase 三相电容480Vac额定电压，长方形（电网电压380Vac选配7%电抗） |
Aerovox P/N
产品料号 |
KVAR Rating under 480Vac
在480Vac下的额定千乏数
kvar |
Rated Current
额定电流
(A) |
Rated Capacitance
额定电容值
(µF) |
Dimensions
尺寸
D x H (mm) |
Approx Weight
大约重量
(kg) |
| ADCA010RC33D |
10 |
12 |
138 |
200X130X350 |
4.90 |
| ADCA015RC33D |
15 |
18 |
207 |
200X130X350 |
5.00 |
| ADCA020RC33D |
20 |
24 |
276 |
200X130X350 |
6.20 |
| ADCA025RC33D |
25 |
30 |
346 |
200X130X350 |
6.90 |
| ADCA030RC33D |
30 |
36 |
415 |
200X130X350 |
7.00 |
| ADCA035RC33D |
35 |
42 |
484 |
330X130X350 |
9.20 |
| ADCA040RC33D |
40 |
48 |
553 |
330X130X350 |
9.90 |
| ADCA045RC33D |
45 |
54 |
622 |
330X130X350 |
10.00 |
| ADCA050RC33D |
50 |
60 |
691 |
330X130X450 |
12.30 |
| ADCA060RC33D |
60 |
72 |
829 |
330X130X450 |
13.10 |
| ADCA070RC33D |
70 |
84 |
968 |
330X130X570 |
15.70 |
| ADCA075RC33D |
75 |
90 |
1037 |
330X130X570 |
16.60 |
| ADCA080RC33D |
80 |
96 |
1106 |
330X130X570 |
17.10 |
| ADCA090RC33D |
90 |
108 |
1244 |
330X130X570 |
17.90 |
| ADCA100RC33D |
100 |
120 |
1382 |
400X130X570 |
20.50 |
| 525 Vac, 50 Hz, 3 Phase 三相电容525Vac额定电压，长方形（电网电压380Vac选配13-14%电抗） |
Aerovox P/N
产品料号 |
KVAR Rating under 525Vac
在525Vac下的额定千乏数
kvar |
Rated Current
额定电流
(A) |
Rated Capacitance
额定电容值
(µF) |
Dimensions
尺寸
D x H (mm) |
Approx Weight
大约重量
(kg) |
| ADCA010RH33D |
10 |
11 |
116 |
200X130X350 |
4.90 |
| ADCA015RH33D |
15 |
16 |
173 |
200X130X350 |
5.00 |
| ADCA020RH33D |
20 |
22 |
231 |
200X130X350 |
6.20 |
| ADCA025RH33D |
25 |
27 |
289 |
200X130X350 |
6.90 |
| ADCA030RH33D |
30 |
33 |
347 |
200X130X350 |
7.00 |
| ADCA035RH33D |
35 |
38 |
404 |
330X130X350 |
9.20 |
| ADCA040RH33D |
40 |
44 |
462 |
330X130X350 |
9.90 |
| ADCA045RH33D |
45 |
49 |
520 |
330X130X350 |
10.00 |
| ADCA050RH33D |
50 |
55 |
578 |
330X130X450 |
12.30 |
| ADCA060RH33D |
60 |
66 |
693 |
330X130X450 |
13.10 |
| ADCA070RH33D |
70 |
77 |
809 |
330X130X570 |
15.70 |
| ADCA075RH33D |
75 |
82 |
867 |
330X130X570 |
16.60 |
| ADCA080RH33D |
80 |
88 |
924 |
330X130X570 |
17.10 |
| ADCA090RH33D |
90 |
99 |
1040 |
330X130X570 |
17.90 |
| ADCA100RH33D |
100 |
110 |
1155 |
400X130X570 |
20.50 |
| 800 Vac, 50 Hz, 3 Phase 三相电容800Vac额定电压，长方形（电网电压690Vac选配7%电抗） |
Aerovox P/N
产品料号 |
KVAR Rating under 800Vac
在800Vac下的额定千乏数
kvar |
Rated Current
额定电流
(A) |
Rated Capacitance
额定电容值
(µF) |
Dimensions
尺寸
D x H (mm) |
Approx Weight
大约重量
(kg) |
| ADCA010RB33D |
10 |
7 |
50 |
200X130X350 |
4.90 |
| ADCA015RB33D |
15 |
11 |
75 |
200X130X350 |
5.00 |
| ADCA020RB33D |
20 |
14 |
100 |
200X130X350 |
6.20 |
| ADCA025RB33D |
25 |
18 |
124 |
200X130X350 |
6.90 |
| ADCA030RB33D |
30 |
22 |
149 |
200X130X350 |
7.00 |
| ADCA035RB33D |
35 |
25 |
174 |
330X130X350 |
9.20 |
| ADCA040RB33D |
40 |
29 |
199 |
330X130X350 |
9.90 |
| ADCA045RB33D |
45 |
32 |
224 |
330X130X350 |
10.00 |
| ADCA050RB33D |
50 |
36 |
249 |
330X130X450 |
12.30 |
| ADCA060RB33D |
60 |
43 |
299 |
330X130X450 |
13.10 |
| ADCA070RB33D |
70 |
51 |
348 |
330X130X570 |
15.70 |
| ADCA075RB33D |
75 |
54 |
373 |
330X130X570 |
16.60 |
| ADCA080RB33D |
80 |
58 |
398 |
330X130X570 |
17.10 |
